Factory Price 1500W 2000W 3000W CNC Fiber Laser Cutter Cutting Machine for Metal Sheet Carbon Stainless Steel Aluminum
Factory Price 1500W 2000W 3000W CNC Fiber Laser Cutter Cutting Machine for Metal Sheet Carbon Stainless Steel Aluminum
Regular price
¥741.00 CNY
Regular price
¥741.00 CNY
Sale price
¥741.00 CNY
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Products Description
2000W 3000W 4000W 6000W Fiber Laser Cutting / Laser Cutter for Metal / Stainless Steel / Carbon Steel / Copper / Aluminum Steel Fiber Laser Cutting Machine
fiber laser cutting machine which consist of machine tool,motion parts, electrical equipment control parts, and other assist parts. Via control system to operation three axis motion parts,so it can drive to fiber laser cutting head achieve a stable, accurate, and high speed moving; X and Y axis of aluminium stainless steel sheet cutting machine adopt by imported with original packaging high quality and precision HIWIN linear guide rail, working table adopt by square pipe to welding the overall machine, stress relief annealing treat, the max load-bearing of mesa could get 500 KG, it also has universal ball bearing, machine external set up peripheral clamping device, use full enclosed dust proof device, photoelectric sensor, and other precise positioning parts to ensure accuracy of the transmission.
Technical Parameter
Code name of width |
3015 |
||||||
Maximum material width (mm) |
3000×1500 |
||||||
X axis travel (mm) |
1520 |
||||||
Y axis travel (mm) |
3020 |
||||||
Z axis travel (mm) |
80 |
||||||
X/Y axis positioning accuracy |
±0.05mm/m |
||||||
X/Y axis repeat positioning accuracy |
≤0.04mm |
||||||
Maximum positioning speed |
140m/min |
||||||
Maximum acceleration |
1.2G |
||||||
Slit width |
0.1-0.5mm(Measured value below 3mm thickness) |
||||||
Minimum setting unit |
0.001mm |
||||||
Floor area of machine tool (mm) |
6000×3000 |
||||||
Host volume (mm) |
4850*2250*1700 |
||||||
CNC system |
CypCut |
||||||
Monitor |
19″LCD |
||||||
Transfer method |
Gear rack dual drive |
||||||
Maximum load-bearing capacity of worktable (tons) |
1 |
||||||
Machine weight (tons) |
3 |
||||||
Total installed power consumption (approximately) |
Laser power:1000W |
17kW |
|||||
Laser power:1500W |
19.5kW |
||||||
Laser power:2000W |
22kW |
||||||
Power requirements |
AC380V,50Hz;3P+N+PE |
||||||
Total power protection level |
IP54 |
||||||
Cutting Performance
Material |
1000W cutting performance |
1500W cutting performance |
2000W cutting performance |
||||||
Carbon steel |
stable cutting |
≤ 8mm |
stable cutting |
≤ 12mm |
stable cutting |
≤ 16mm |
|||
Limit cut |
12mm |
Limit cut |
16mm |
Limit cut |
20mm |
||||
Stainless steel |
stable cutting |
≤ 4mm |
stable cutting |
≤ 6mm |
stable cutting |
≤ 7mm |
|||
Limit cut |
6mm |
Limit cut |
8mm |
Limit cut |
10mm |
||||
Material |
3000W cutting performance |
4000W cutting performance |
6000W cutting performance |
||||||
Carbon steel |
stable cutting |
≤ 20mm |
stable cutting |
≤ 22mm |
stable cutting |
≤ 25mm |
|||
Limit cut |
25mm |
Limit cut |
25mm |
Limit cut |
30mm |
||||
Stainless steel |
stable cutting |
≤ 9mm |
stable cutting |
≤ 10mm |
stable cutting |
≤ 14mm |
|||
Limit cut |
12mm |
Limit cut |
14mm |
Limit cut |
20mm |
||||
Material |
12000W cutting performance |
15000W cutting performance |
20000W cutting performance |
||||||
carbon steel |
stable cutting |
≤ 35mm |
stable cutting |
≤ 40mm |
stable cutting |
≤ 45mm |
|||
Limit cut |
50mm |
Limit cut |
60mm |
Limit cut |
70mm |
||||
Stainless steel |
stable cutting |
≤ 30mm |
stable cutting |
≤ 35mm |
stable cutting |
≤ 40mm |
|||
Limit cut |
50mm |
Limit cut |
70mm |
Limit cut |
80mm |
||||
After Sales Service
1. 7*24 hour
2. Response time<12 hours
3.Online support
4.Product replacement
5. Customer field service
6. Backup products during repairing for long time cooperators
* International warranty ONLY valid if products are purchased directly from Horizon Laser or authorized local distributors/agents.
2. Response time<12 hours
3.Online support
4.Product replacement
5. Customer field service
6. Backup products during repairing for long time cooperators
* International warranty ONLY valid if products are purchased directly from Horizon Laser or authorized local distributors/agents.
Packing & Delivery
The normal package is wooden pallet and wooden case. The wooden pallet and wooden box will be fumigated.
If container is too tigher,we will use pe film for packing or pack it according to customers special request.
If container is too tigher,we will use pe film for packing or pack it according to customers special request.
FAQ
